Y Series Stainless Steel Braided Smooth Inner PTFE Tubing
Y Series PTFE Hose Premium PTFE hydraulic hose engineered for high-performance fluid transfer in demanding industrial environments. Main Features High-Grade Raw Material : Inner tube crafted from Japanese Daikin 302 dispersion PTFE resin, ensuring exceptional chemical resistance and ultra-pure...
- Product Introduction
Y Series PTFE Hose
Premium PTFE hydraulic hose engineered for high-performance fluid transfer in demanding industrial environments.
Main Features
Premium Raw Material Inner tube made of Japanese Daikin 302 dispersion PTFE resin, for excellent chemical resistance and ultra-pure fluid transfer.
Industry-Leading Performance: Exceeds SAE 100R14 standards for reliable pressure resistance and stability on critical hydraulic systems.
Strong Reinforcement: One layer of SS304 stainless steel wire braid provides greater burst resistance, mechanical strength, and durability in extreme temperatures.
Extreme Thermal Stability Remains intact from -50°C to +180°C (-58°F to +356°F) for continuous high heat operation.
Universal Fluid Compatibility – Perfect for aggressive fluid transfer applications, it is inert to virtually all hydraulic oils, chemicals and corrosive fluids.
Applications
The PTFE core tube is FDA 21 CFR177.1550 compliant for use in food & beverage processing, pharmaceutical manufacturing and sanitary fluid handling.
It is widely used in hydraulic systems, chemical processing plants, petrochemical refineries, automotive manufacturing and aerospace engineering .
Ideal for the conveying of high temperature oils, corrosive chemicals and high purity gases where contamination control is critical.
Construction
Inner Tube: Smooth-bore PTFE tube (light blue semi-transparent) for low friction, easy cleaning, and minimal fluid residue.
Reinforcement: 1 layer of SS304 stainless steel wire braid for pressure resistance and mechanical protection.
Temperature Range
Permanent Operating Temperature: -50°C to +180°C (-58°F to +356°F)
Technical Specifications
| Part No. | I.D. (DN) | I.D. (Inch) | I.D. (mm) | O.D. (Inch) | O.D. (mm) | MAX Working Pressure (BAR) | MAX Working Pressure (PSI) | MIN Burst Pressure (BAR) | MIN Burst Pressure (PSI) | MIN Bend Radius (mm) | Weight (KG/M) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1Y-3 | 3.2 | 1/8" | 6.2 | 0.24 | 6.2 | 245 | 3552 | 1050 | 15225 | 35 | 0.075 |
| 1Y-4 | 5 | 3/16" | 8 | 0.31 | 8 | 192 | 2791 | 770 | 11165 | 45 | 0.095 |
| 1Y-5 | 6.3 | 1/4" | 9.2 | 0.36 | 9.2 | 180 | 2610 | 720 | 10440 | 55 | 0.115 |
| 1Y-6 | 8 | 5/16" | 11.2 | 0.44 | 11.2 | 192 | 2791 | 770 | 11165 | 80 | 0.142 |
| 1Y-7 | 9.7 | 3/8" | 13 | 0.51 | 13 | 172 | 2500 | 690 | 10000 | 100 | 0.173 |
| 1Y-8 | 10.3 | 13/32" | 13.5 | 0.53 | 13.5 | 170 | 2465 | 680 | 9860 | 110 | 0.2 |
| 1Y-10 | 12.7 | 1/2" | 16.5 | 0.65 | 16.5 | 160 | 2320 | 640 | 9280 | 125 | 0.242 |
| 1Y-12 | 16.2 | 5/8" | 19.5 | 0.77 | 19.5 | 137 | 1993 | 550 | 7975 | 160 | 0.29 |
| 1Y-14 | 19 | 3/4" | 23.5 | 0.93 | 23.5 | 95 | 1377 | 380 | 5510 | 200 | 0.43 |
| 1Y-16 | 22.2 | 7/8" | 26.5 | 1.04 | 26.5 | 87 | 1268 | 350 | 5075 | 240 | 0.48 |
| 1Y-18 | 25 | 1" | 29.8 | 1.17 | 29.8 | 75 | 1087 | 300 | 4350 | 250 | 0.54 |
Why Choose Our Y Series PTFE Hose?
✅ Unmatched Durability: Designed with Daikin PTFE and SS304 braid for long-lasting performance in harsh industrial settings.
✅ Regulatory Compliance: FDA-approved inner tube for Food, Pharmaceutical and Sanitary applications.
✅ Flexible sizing to fit a wide range of diameters and pressure ratings to be used in a variety of industries worldwide.
✅ Meets All Standards: Exceeds SAE 100R14 and ensures perfect worldwide hydraulic systems compatibility.
